1. Features
2. Technical Specifications
3. Installation
Remove the back cover from the keypad using the supplied special screw driver
Drill 2 holes on the wall for the self-tapping screws and hole for the cable
Put the supplied rubber bungs to into the two holesFix the back cover firmly on the wall with 2self-tapping screws
Thread the cable through the cable hole
Attach the keypad to the back cover. (as following illustration)
4. Wiring
Colour |
Function |
Description |
||||||||||||||
Green |
D0 |
WG output D0 |
||||||||||||||
White |
D1 |
& |
